Working principle of paper slitting machine

The paper slitting machine consists of a frame, transmission system, feeding and unloading machinery and tension control device, traction components, slitting bracket, waste winding and discharge device, etc. It divides the raw material into several independent units, and its working principle is to fix the raw material on the feeding shaft. One end of the feeding shaft is equipped with a magnetic powder tension controller to maintain the required tension of the raw material. Then, it is pulled by a pair of rubber rollers and cut into several strips by a blade. Then it is guided by various guide rollers to the A and B winding shafts for winding the finished product. Its transmission is driven by the main motor to synchronously operate the traction rubber roller and the receiving shaft, achieving the purpose of traction feeding and finished product receiving.
1. Rack and transmission system: The rack consists of left and right wall panels, support blocks, and feeding machinery The transmission system is mainly used to pull raw materials and roll finished products. It is powered by a variable frequency stepless speed regulating motor through a motor V-belt to operate the traction rubber roller. The main traction rubber roller is closely attached to the driven traction rubber roller and runs synchronously to pull the raw materials. The active traction roller drives the lower circular blade shaft to run synchronously to achieve better cutting requirements. The lower circular blade shaft drives winding A and winding B to run synchronously, thus achieving the purpose of material collection.
2. Material receiving mechanism and its tension device: The material receiving mechanism mainly consists of components such as chains, synchronous wheels, magnetic powder clutches, and inflatable shafts Two winding shafts are controlled by a single motor, and the tension of the winding shaft can be changed by adjusting the current of the magnetic powder clutch.
3. Traction component: The traction component mainly consists of a pair of traction rubber rollers and several hard oxidized aluminum rollers, which play a role in pulling and collecting raw materials for finished product winding Its power comes from the motor transmitting to the active traction rubber roller through a V-belt to make it run.
4. Slitting knife holder: The slitting knife holder has round knife slitting and straight knife slitting The operating handle can adjust the shear gap between the circular blade edge and the groove of the pad sleeve by making a slight axial movement of the circular blade through a flat cam.
5. Waste collection and discharge: Waste is discharged through air ducts using the wind power of a blower.
6. Material feeding mechanism and automatic correction: The material feeding mechanism mainly consists of a feeding shaft, support block, cylinder, base, left and right moving seats, etc. The automatic correction device consists of a photoelectric head, correction guide roller, left and right brackets, correction moving plate, ball nut and screw, synchronous motor, and left and right limit switches.
